MIT5XX/10XX
1
st
Used On:
SERVICE MANUAL
Isolated Comms
Or gate
RS 232 Buffer &
Iso Tx Drive
Iso Tx
RS232 Level Translate
& + rail generate
Regulate &
-- rail generate
USB/RS232
Convertor
+10v iso
--10v iso
3.3v iso 3.3v USB
3.3v iso
RS232 Connect
USB detect
USB Connect
Instrument
Connect
Switch
USB Rx
USB Tx
Buffer Level
Translate
Opto
Tx
Rx
