SERVICE MANUAL
7.3 Interface 10 & 20 BOM – circuit diagram 6270-296 issue 2
Value Part Reference PARTNUM
1.00n C2 C8 C20 C25 32000-027
1.00uF C6 32000-044
100.00n C9 C19 C26 C27 C28 C30 C31 C32 32000-029
100.00n C11 C16 32000-018
10.00uF C12 32000-038
10.00uF C13 C15 32000-023
22.00pF C17 C21 C22 C23 32000-043
470.00nF C18 C29 32000-042
LL4148 D2 31000-002
BAS16 D3 31300-003
LTC1383CS IC1 30000-088
74AHCT1G08GW IC2 30000-172
24C64 IC7 30000-102
24C64 IC8 TMP-287
TUSB3410 IC10 30000-188
74AHCT1G126GW IC11 30000-171
0 PL2 25965-178
100.00K R1 R17 R27 R33 R34 R38 33000-042
1.00K R2 R13 R18 R19 R36 R37 R41 33000-031
4.70K R4 R11 R28 R39 33000-035
10.00K R5 R6 R7 R8 R9 R10 R15 R21 R22 R31 R35 R40 33000-037
1.50K R20 33000-032
15.00K R23 33000-112
3.00R R25 33000-011
30.00K R26 33000-070
30.00R R29 R30 33000-015
1.00M R32 33000-044
6.80M R42 26836-731
0 SK1 35965-002
0 SK2 25965-186
BCW32 TR1 TR2 TR3 TR4 TR6 TR7 31000-001
BCF29 TR5 31000-004
LM1117-3.3 VR1 30200-004
0 XL1 28900-089
