AF008-02-1201
71
Number
Issue
Date
CN Number
1
2-
2
17-01-07
22933
Compiled
By:
S.Mynott
Date
Compiled:
08/08/06
MIT5XX/10XX
1
st
Used On:
SERVICE MANUAL
7.4 Isolated Board BOM – circuit diagram 6270-306 issue 2.
Value Part Reference PARTNUM
100.00n C1 C9 C10 C19 32000-029
1.00n C2 C8 C20 C25 32000-027
3.30n C3 26970-131
10.00uF C4 C12 32000-038
10.00uF C5 C13 C14 C15 32000-023
1.00uF C6 C24 32000-044
100.00n C7 C16 32000-018
22.00pF C17 C21 C22 C23 32000-043
470.00nF C18 32000-042
LL4148 D1 D2 31000-002
BAS16 D3 31300-003
MAX250 IC1 30100-006
74AHCT1G08GW IC2 30000-172
6N136 IC3 IC4 IC5 IC6 29350-003
MAX251 IC9 30100-005
TUSB3410 IC10 30000-188
0 PL2 25965-178
0 PL3 25960-127
100.00K R1 R17 R27 R33 R34 R38 33000-042
1.00K R2 R18 R19 R36 R37 (R39 not fitted) 33000-031
4.70K R3 R4 R16 R24 R28 33000-035
10.00K R5 R6 R7 R8 R9 R10 R21 R22 R31 R35 33000-037
1.50K R20 33000-032
15.00K R23 33000-112
3.00R R25 33000-011
30.00K R26 33000-070
30.00R R29 R30 33000-015
1.00M R32 33000-044
220R R12 33000-103
680R R11 33000-135
0 SK1 35965-002
BCW32 TR1 TR2 TR3 TR4 TR6 31000-001
BCF29 TR5 31000-004
0 TX1 35200-002
LM1117-3.3 VR1 30200-004
0 XL1 28900-089
To Next Page
