SERVICE MANUAL
7.5 Power Board BOM – circuit diagram 6270-295 issue 5
PSU Board Bill of Materials
Value Part Reference PARTNUM
KBU6J BR1 28920-038
100pF C1 C13 26970-165
100nF C2 C5 C7 C8 C25 32000-004
100U C3 26970-162
10nF C4 32000-025
100u C6 27889-976
1m C9 C16 27890-041
470n C10 27889-868
4.7nF C11 C23 32000-039
100n C12 C20 27889-836
330nF C14 26970-171
100n C15 32000-029
100nF C17 C22 26970-159
470u C19 26970-080
10uF C21 32000-022
100n C26 27889-827
47u C27 26970-175
BYW29E-100 D2 28920-073
1N5355B D3 D4 28920-065
BZX79C3V9 D5 28863-353
LL4148 D6 D20 31000-002
MBRS2040LT3 D10 D18 D19 31300-012
BZT03C68 D11 28920-044
BZT03C82 D13 29500-003
UF4006 D14 29400-013
1N4148 D15 28433-801
MBR20200CT D17 29400-020
MMSZ4692 D21 31400-007
0 FS1 25413-280
0 HS1 HS2 HS5 28863-365
0 HS6 27960-056
TL061CD IC1 30000-010
TLC271ACD IC2 30000-003
MCT2 IC3 28900-044
TOP245Y IC4 20100-004
TL1431CD IC5 31200-009
0 L1 27900-054
0 L2 6132-053
INDUCTOR L3 35200-026
0 PL5 25960-120-03
0 PL7 25960-120-02
0 PL8 25960-043
100R R2 26836-089
100K R3 R7 R12 R21 33000-042
1M R4 R5 R32 R33 33000-044
120K R6 26837-121
4.7K R8 26900-136
1K R13 R16 33000-010
180R R14 26837-101
2R R15 R24 26900-272
10K R17 R26 R30 R48 R54 R55 R56 R59 33000-037
1K R18 R20 R22 R27 R28 R41 33000-031
750R R19 33000-023
330R R23 33000-030
47K R29 R31 33000-040
1.5K R34 26900-053
3.3R R35 26900-286
470R R36 26837-211
1M R37 R38 26837-169
300R R39 33000-068
