Megger MIT510 - Page 74

AF008-02-1201
74
Number
Issue
Date
CN Number
6
1
7
2-
999
2
17-01-07
22933
Compiled
By:
S.Mynott
Date
Compiled:
08/08/06
MIT5XX/10XX
1
st
Used On:
SERVICE MANUAL
7.6 Measurement Board BOM – circuit diagram 6270-298 issue 12
Measurement Board Bill of Materials
Value Part Reference PARTNUM
100nF C2 C4 C5 C7 C10 C12 C13 C14 C15 C35 C38 C40 C43 C44 C45 C46 C47 C55 32000-004
C56 C61 C63 C65 C70 C79 C80 C81 C82 C83 C84 C85 C90 C91 C93 C115
C125 C127 C128 C129 C130 C131 C132 C116 C118 C124 C133 C138 C139
C140 C141 C145 C146
10nF C3 C9 C89 C114 C126 C134 C135 C143 C144 32000-025
1u C6 C54 C57 C95 C102 C103 C104 C105 C106 C107 C108 C109 C110 C111 27889-996
C112 C113 C119 C120 C121
100n C8 C11 C58 C59 C122 C123 27889-827
100uF C17 32000-037
100uF C18 32000-021
100n C19 C20 C50 C60 C86 C87 C88 C97 C101 C136 32000-029
10uF C21 C22 C48 C49 C64 32000-023
10pF C32 C33 C36 C37 32000-032
10uF C39 C41 C92 C137 C147 32000-038
3.3nF C51 C117 32000-026
1uF C62 C98 C99 C100 32000-044
33p C68 C69 32000-003
1n C142 32000-027
1N5400 D2 D3 28863-095
LL4148 D7 D9 D10 D15 D17 D18 D20 D21 D22 D23 D24 D25 D28 D35 D36 31000-002
BZX79C5V6 D8 28474-273
LST670-JL D11 D12 D13 D14 D16 31000-017
P01102BL D19 31900-001
MBRS130LT3 D29 D32 D33 31000-021
BZX84C3V0 D30 D31 31400-003
BZX79C3V9 D34 28863-353
0 FS1 25950-034
LM339 IC1 IC2 IC27 31000-005
TLC2652CN IC3 IC13 IC23 20000-147
MCP601 IC4 30200-048
MCP2120-I/SL IC7 30000-190
TFDU4100 IC8 31350-005
ADS1240 IC9 30100-015
ADOP07DN IC11 IC12 IC22 IC25 IC26 28900-041
24C64 IC14 30000-102
M30620F CPFP IC15 6139-201
CA3140E IC16 20000-140
4538 IC19 IC20 30000-006
74HC32 IC21 30000-051
4066 IC24 IC28 30000-033
0 L1 27920-043
INDUCTOR L2 35200-026
LINK DUMMY LKD3
LINK DUMMY LKD4
LINK DUMMY LKD6
0 PL1 PL3 PL4 PL120 25930-055
PLUG20EDGE PL5
0 PL10 PL117 PL118 25960-045-03
0 PL11 PL12 PL13 PL14 PL15 PL16 25960-118
PLUG01/2P PL119 25257-668
