Megger MIT510 - Page 75

AF008-02-1201
75
Number
Issue
Date
CN Number
6
1
7
2-
999
2
17-01-07
22933
Compiled
By:
S.Mynott
Date
Compiled:
08/08/06
MIT5XX/10XX
1
st
Used On:
SERVICE MANUAL
1K R1 R5 R17 R22 R36 R49 R68 R79 R82 R83 R84 R117 R119 R261 R289 R290 33000-031
R305 R307 R311 R314 R315 R316 R321
100K R3 R9 R11 R19 R26 R32 R37 R60 R63 R75 R76 R77 R78 R95 R99 R100 R101 33000-042
R102 R110 R118 R120 R254 R264 R265 R279 R280 R281 R282 R298
R310 R324 R327 R328
10K R7 R14 R24 R27 R28 R30 R40 R41 R44 R47 R52 R55 R57 R58 R59 R61 33000-037
R69 R73 R80 R81 R87 R88 R90 R91 R93 R94 R96 R104 R105 R106 R107
R108 R109 R111 R112 R113 R114 R115 R122 R226 R227 R228 R229 R230
R231 R232 R233 R234 R235 R236 R237 R238 R239 R240 R241 R242 R243
R244 R245 R246 R247 R266 R268 R273 R283 R284 R285 R286 R287 R288
R293 R294 R295 R296 R297 R300 R301 R302 R313 R319 R320 R322 R323
R325 R326
2.2K R10 R12 R18 R38 R53 R54 R258 R259 R312 33000-033
100R R13 R20 R253 R260 R262 R303 R304 R309 R329 R330 R331 33000-029
1R R16 33000-014
10R R21 R42 R43 R45 R46 R85 R86 R89 33000-021
6.8K R23 33000-036
1M R33 R48 R62 R121 R248 R249 33000-044
10M R35 26837-130
22K R66 R255 R256 R257 R277 33000-038
680R R97 33000-135
33K R116 R269 R270 R271 R272 R275 R276 33000-039
0R R224 R225 R299 33000-105
10M R267 R308 33000-005
1.5M R278 33000-063
10K RV1 34000-001
SCREEN 4PIN SC1 5131-396
0 SK1 SK2 25418-217
0 SK10 35965-002
0 SW1 SW2 35975-001
2N4393 TR1 TR6 TR14 TR15 TR16 28863-165
BCW32 TR4 TR12 TR13 31000-001
BCF29 TR5 TR17 31000-004
ZRC250 VR1 31000-029
7805 VR2 28863-138
7808 VR3 28863-321
7908 VR4 28900-109
0 XL1 XL2 35000-012
0 XL4 28900-031
