MIT5XX/10XX
1
st
Used On:
SERVICE MANUAL
7.7 5Kv Board BOM – circuit diagram 6270-300 issue 10
5kv Board Bill of Materials
Value Part Reference PARTNUM
47n C1 C6 C8 C9 C12 C14 26970-087
220u C2 C4 27889-869
100nF C3 C5 C24 C27 32000-004
1n C7 32000-027
33nF C10 32000-019
470nF C11 32000-042
47n C13 32000-008
100n C20 C33 C41 27889-836
100n C21 C35 32000-029
10nF C22 C25 32000-025
47u C23 26970-103
10n C26 27889-809
2.2n C28 C29 32000-006
470p C30 32000-002
100pF C31 32000-030
470u C32 C42 26970-080
220u C34 C36 27889-700
47nF C39 26970-150
10n C40 27889-890
LL4148 D16 D48 (D9 & D11 not fitted) 31000-002
1N4002 D15 D18 D19 D20 28862-927
BY203-20S D21 D22 D23 D24 D25 D31 29400-019
BZX79C10 D36 28920-018
BYW29E-100 D43 28920-073
BZT03C18 D44 D50 28920-024
BZX79C7V5 D45 28862-891
HLMP1340 D47 28920-085
BZT03C68 D49 28920-044
BYV10-30 D51 28920-067
BZX84C10 D52 D53 31400-006
0 FS1 FS2 25950-016
CA3240E IC1 20000-020
LM311 IC4 31000-012
CA3140M IC5 30000-013
LM339 IC6 31000-005
LINK DUMMY LKD1
0 PL2 PL3 PL4 PL10 PL11 PL12 25424-932
0 PL5 PL13 25257-668
0 PL7 PL8 25960-045-03
100M R1 R10 26836-558
750K R2 26837-066
10K R6 R7 R67 R69 R77 R83 R92 R95 R115 R118 R119 R123 33000-037
12K R8 33000-059
4.7K R9 R18 R58 R71 R91 33000-035
8.2K R11 R15 R20 R27 R51 R148 R150 R152 R153 R154 26837-148
6.8M R13 26836-731
10K R17 R96 R34 R35 33000-012
100K R21 R28 33000-042
120K R29 33000-018
1M R30 R31 R116 33000-044
5K R32 26950-010
