2 - 6 VM600 MPS quick start manual MAMPS-QS/E
Edition 2 - October 2018
Card features and operation
OPERATING THE SYSTEM
Figure 2-4: IOC8T panel (rear of rack)
SLOT ERROR indicator
The colour of this LED indicates whether the
IOC8T is installed in the correct slot of the
rack:
* Green – The card is in the correct slot
* Red – Slot number mismatch.
Connector J1
(mating connector with 24
cage clamp terminals)
Connector J2
(mating connector with 24
cage clamp terminals)
Connector J3
(mating connector with 20
cage clamp terminals)
Connector J4
(mating connector with
12 screw terminals)
