2 - 10 VM600 MPS quick start manual MAMPS-QS/E
Edition 2 - October 2018
Card features and operation
OPERATING THE SYSTEM
2.1.7 RLC16 relay card
Figure 2-7 shows an RLC16 relay card both a) without mating connectors and b) with mating
connectors.
2.1.8 IRC4 relay card
Figure 2-7 shows an IRC4 relay card both a) without mating connectors and b) with mating
connectors.
The screw-terminal connectors of an RLC16 relay card can be connected to
hazardous voltages (up to 250 V
AC
nominal rate voltage).
Refer to the VM600 machinery protection system (MPS) hardware manual
and observe all safety instructions before installing and using RLC16 relay
cards.
The screw-terminal connectors of an IRC4 relay card can be connected to
hazardous voltages (up to 250 V
AC
nominal rate voltage).
Refer to the VM600 machinery protection system (MPS) hardware manual
and observe all safety instructions and before installing and using IRC4
relay cards.
