10 Attachment: Technical Information
10.1 Technical Specifications SYNCBOX N2X
Power Supply: Nominal: 48 V DC
(max. 20 - 60 V DC)
Input Fuse: Medium Slow 500 mA / 250 V
Protection Rating: IP20
Power Consumption: 7,5 W
Humidity: max. 85%
Ambient Temperature: 0 ... 50
◦
C
Accuracy of pulse outputs: PTP: +/- 100 ns (relative to the used
IEEE 1588 Grandmaster Clock, after
initial synchronization phase)
NTP: +/- 1 ms (relativ to NTP when using
a local time server)
* after warm-up period
Precision Time Protocol
(IEEE 1588) UDP/IPv4 (L3) or IEEE802.3 (L2) Multicast
E2E, E2E Hybrid or P2P Delay Mechanism
PTP Subdomains (0-255)
Power Profile compatible
Network Time Protocol (NTP) Up to seven configurable external NTP Time Server
Min. and max. polling interval (8s – 1024s)
Standard NTP options (noselect, true, prefer, iburst)
SyncBox/N2X
LAN
OUT 3OUT 2OUT 1
ACO
+
-
20 - 60V
COM 0
130
105
160
25
TOP
BOTTOM
44
25
R
3
,
2
DIN Rail option
