Melco EP 1 - Drawing out the Bobbin Thread

2-2
EP 1 Operation Manual Melco Embroidery Systems
Figure 2-4
7. Pass the thread through the embroidery
thread take-up lever from the left to the
right; and then pull it downward toward
the first lower thread guide.
Figure 2-5
Figure 2-6
8. Hook the thread into the two lower
thread guides as you continue to pull it
downward.
Figure 2-7
Figure 2-8
9. Hook the thread into the needle bar thread guide from the left
side.
Figure 2-9
10. Pass the thread into the needle from the front to the rear (use a
threader if desired).
Figure 2-10
11. After threading the needle, position the embroidery thread through
the presser foot hole. You may do this now by threading it as you
would the eye of a needle or in the following procedure while
drawing out the bobbin thread.
