6-4
EP 1 Operation Manual Melco Embroidery Systems
10. Place 1-2 drops of oil at both locations
where the shaft passes through a bushing, as
shown in Figure 6-10, once each month.
Close the face cover when done.
11. After lubrication, the fabric and thread dur-
ing the next embroidery operation may
become contaminated with oil. To keep from
contaminating actual garments, sew on a
scrap piece of fabric for a short time before
continuing.
NOTE: Never use any oil other than the sewing machine oil recommended by Melco (one contain-
er of oil is included with the machine).
Replacement Parts
Fuses
There are two operator-replaceable fuses. 2 spare fuses are
included with your machine. To replace a fuse, follow these
steps:
1. Turn off the power and disconnect the power cord.
2. Directly above where the power cord plugs in is a small
plastic cover (see Figure 6-11). Use your fingernails to
unclip each side of this cover in the locations shown in
Figure 6-11.
3. When the cover is unclipped, pull on the cover to
remove the fuse holder (see Figure 6-12).
4. Change the fuse(s), then replace the fuse holder.
5. Reconnect the power cord and turn on the power.
Figure 6-10
1-2 drops of
oil at each
location.
Figure 6-11
Plastic cover
Figure 6-12
