LOCATION OF CONTROLS
1
2
12
3
4
9
10
8
5
7
6
11
13
14
15
16
17
18
19
MAIN UNIT
1. Open Door Switch
2. Display
3. TITLE Button
4. STOP (
■) Button
5. SETUP Button
6. DC IN Jack 12V
z
(AC ADAPTER PART NO.
090E-0001731-00*,
CAR ADAPTER PART NO.
090E-1001731-01*)
7. Skip o Button
8. POWER Indicator
9. DISC COMPARTMENT DOOR
PUSH OPEN Button
10. Remote Sensor
11. DISPLAY Button
12. SCREEN MODE Button
13. MENU Button
14. Skip
n Button
15. PLAY/PAUSE (
®p) Button
16. OK Button
17. Navigation (
π,†,√,®) Buttons
18. POWER ON/OFF Switch
19. CHARGING Indicator
*Consumer Replaceable Part
(See page 44 to order.)
