15
ENGLISH
OUT
IN
OUT
IN
OUT
IN
NOTE: IF A VHF OR UHF
ANTENNA IS USED, SET THE TV/
CATV MENU OPTION TO THE
"TV" MODE.
NOTE: IF A VHF OR UHF
ANTENNA IS USED, SET THE TV/
CATV MENU OPTION TO THE
"TV" MODE.
NOTE: IF A VHF OR UHF
ANTENNA IS USED, SET THE TV/
CATV MENU OPTION TO THE
"TV" MODE.
COMBINER
75/300 OHM INPUTS
75 OHM OUTPUT
(NOT SUPPLIED)
VCR
VCR
VCR
MATCHING TRANSFORMER
300 OHM INPUT
75 OHM OUTPUT
(NOT SUPPLIED)
This VCR has a single 75 ohm antenna input for connection to an antenna (VHF/UHF) or cable (CATV) system.
If you have separate VHF and UHF antennas (number 3 below), use a combiner to connect the antennas to
the VCR.
