Mendota ML39-PF2 - General Appliance Specifications

85-03-00955 Page| 11
CEILING
NON-COMBUSTIBLE ZONE
37" MIN
ROUGH FRAMING
HEIGHT
35 1/16" MIN
UNIT BASE
TO 8" MANTEL
70" MIN
TO ROOM
CEILING
8" MANTEL DEPTH
AT HEIGHTS SHOWN
58 1/8" MIN
UNIT FLOOR
TO ENCLOSURE
CEILING
51 7/16"
TO CENTERLINE
OF VENT CAP
37"
MIN
48 1/4" MIN OPENING WIDTH
8 3/16 TO VENT
PIPE CENTER
19 1/2 MIN
DEPTH
19 1/2 MIN
FRAMING DEPTH
48 1/4 MIN ROUGH
FRAMING WIDTH
SHEATHING +
FINISH MATERIAL
3" MIN
16" TO GUIDE EDGE
84
59 7/16
21 5/8
59 7/16
4
2
21 5/8
GENERAL APPLIANCE SPECIFICATIONS
High Altitude Installation Information: Prior to installing at altitudes higher than 7500, please contact the Mendota
technical service department for specific venting requirements and venting restrictions.
MINIMUM ROUGH FRAMING DIMENSIONS
WIDTH (IN) HEIGHT(IN) DEPTH (IN)
48-1/4 37” 19-1/2
