85-03-00955 Page| 7
UPPER COVER PLATE
LOWER COVER PLATE
5" X 8" COAXIAL
VENT CONNECTOR
HEAT TRANSFER DUCT
CONNECTION PORTS
5" X 8" COAXIAL
VENT CONNECTOR
NON-COMBUSTIBLE
MATERIALS ONLY
ON HATCH AREA
WOOD FRAMING
STANDOFF TOP
ELECTRICAL SUPPLY
LINE INLET
GAS SUPPLY
INLET
2 3/8
3 3/8
5 5/8
8 3/8
46 3/4
13 3/8
2 7/16
12 1/2
39
50 5/8
7 7/8
36 3/8
19
28 1/8
29 1/8
7 3/4
11 3/8
46 3/4
ML39 FULL VIEW GAS FIREPLACE DIMENSIONS
Removable Cover Plate for Plumbing & Electrical
Access before unit is placed inside framed cavity.
Replace Lower Cover Plate before sliding unit into
framed cavity.
