Mendota ML60 - Page 39

85-03-01147 ML60 Page 39
Approved Vent Systems
NOTE: Additional venting configurations are allowed when using a power vent. Consult the power vent instructions for more
information.
H
APPROVED
NOT ALLOWED
NOT ALLOWED
V1
V2
H
H
V1
APPROVED
40 FEET
MAXIMUM
APPROVEDAPPROVED
APPROVED
APPROVED
NOT ALLOWED
APPROVED
H2
V
H2
H2
V2
V1
V2
V
V
H1
H1
H1
H
STRAIGHT UP,
VERTICAL VENTING
THREE HORIZONTAL DISCHARGE
90° ELBOWS
VERTICAL RISE
TRIPLE 90° ELBOWS
VERTICAL TERMINATION
VERTICAL RISE
TRIPLE 90° ELBOWS
HORIZONTAL TERMINATION
VERTICAL RISE
DUAL 90° ELBOWS
HORIZONTAL TERMINATION
VERTICAL RISE
DUAL 90° ELBOWS
VERTICAL TERMINATION
ZERO VERTICAL
DUAL 90° ELBOWS
VERTICAL TERMINATION
VERTICAL RISE
HORIZONTAL TERMINATION
ZERO VERTICAL
HORIZONTAL TERMINATION
