Section 6 - Storage
Page 128 90-864195070 JUNE 2007
BOAT OUT OF THE WATER
NOTE: Use this procedure if your engine is not equipped with an air actuated single point
drain system or if the single point drain system fails.
1. Place the boat on a level surface to ensure complete draining of the system.
2. Remove three blue drain plugs: one from the distribution housing (lower front, port side)
and two from the seawater pickup pump (front, starboard side).
a
a
6142
a - Blue drain plug
3. Verify that water is draining from each opening.
4. Allow the system to drain for a minimum of five minutes. Mercury MerCruiser
recommends leaving the drain system open while transporting the boat or while
performing other maintenance to ensure that all water is drained.
5. Crank the engine over slightly with starter motor to purge any water trapped in the
seawater pickup pump. Do not allow the engine to start.
6. Prior to launching the boat or starting the engine, close the drain system by installing
the three blue drain plugs.
Multi‑Point Drain (MPD) System
1. Place the boat on a level surface to ensure complete draining of the system.
2. Remove the blue drain plugs from the following locations. It may be necessary to clean
out the drain holes using a stiff piece of wire. Do no until the entire system is drained.
a. Port and starboard side of cylinder block
b. Bottom of exhaust manifolds
10226
M110050
93235672
b
a
a
b
6129
a - Cylinder block drain plug b - Exhaust manifold drain plug
To Next Page
