Section 2 - Getting to Know Your Power Package
90-864195070 JUNE 2007 Page 33
3. Press throttle only/station select button once. The "ACTIVE" light will illuminate to
indicate the remote control station is in control of the engine.
ACTIVE
STATION SELECT
3433
ACTIVE
SYNC
STATION SELECT
a
a
b
THROTTLE
ONLY
THROTTLE
ONLY
b
a - Active light b - Throttle only/station select button
4. The active light will switch off at the original remote control station.
SYNCHRONIZING DUAL HELMS PRIOR TO STATION TRANSFER
Pressing the station select button and holding it in allows the boat operator 10 seconds to
match up the control handle settings at the new station with the handle settings that are at
the old (to be inactive) station. If the handles are not matched, the neutral light will flash.
The light blinks faster as the handles are nearing match position. Once the light stays on
continuously, the handles are matched and the button can be released. Transfer process
is complete and the new station is now in control. If the button is held for over 10 seconds,
the station transfer is cancelled.
Zero Effort Features
c
a
b
5656
a - Shift ever
b - Throttle lever
c - Trim/tilt switch
Shift Lever - Shift functions are controlled by the movement of the shift lever. Shift into
reverse by moving the shift lever to its aft position. Shift into neutral by moving the shift
lever to its center position. Shift into forward by moving the shift lever to its forward position.
Throttle Lever - Throttle functions are controlled by the movement of the throttle lever.
Increase the RPM by moving the throttle lever forward. Achieve Wide Open Throttle (WOT)
by placing the throttle lever in its full forward position. Decrease RPM by moving the throttle
lever back. Achieve minimum RPM (idle) by placing the throttle lever in its full aft position.
Trim/Tilt Switch - Refer to Power Trim.
