MerCruiser 350 MAG MPI User Manual

Section 5 - Maintenance
90-864195070 JUNE 2007 Page 77
Changing
1. Remove the gear lube monitor from the bracket.
6109
a
a - Gear lube monitor
2. Empty the contents into a suitable container.
3. Install the gear lube monitor in the bracket.
4. Bravo One Models: Remove the propeller, lower the sterndrive unit to the full down/
in position, remove the oil fill/drain screw and sealing washer and drain the oil.
a
mc79506-1
b
a - Oil fill/drain screw b - Sealing washer

MerCruiser 350 MAG MPI Specifications

General

Engine Type	V8
Horsepower	300 HP
Ignition System	Electronic ignition
Alternator	65 amp
Compression Ratio	9.4:1
Displacement	5.7L (350 cu in)
Fuel System	Multi-Point Injection (MPI)
Bore x Stroke	4.00" x 3.48" (101.6mm x 88.39mm)
