MAINTENANCE
54
NOTE: Oil level will fluctuate during operation. Check the oil level with a
cold engine before starting.
Check The Input Shaft Housing Oil Level On Driveline Models As Follows:
1. Remove the reservoir level pipe plug "c." The oil level should be even
with the bottom of the hole. If low, fill the input shaft housing "b"
through the top fill pipe plug hole "a" until oil flows from the reservoir
level plug hole "c."
a - Fill pipe plug hole
b - Input shaft housing
c - Reservoir level pipe plug
Tube Ref.
No.
Description Where Used Part No.
Torco MTF Gear Oil
Transom input shaft
reservoir and dry
sump drive
92‑849684‑1
2. Re‑install the reservoir level pipe plug and the top fill plug.
