MAINTENANCE
66
Driveline Models Only
1. Place a container below the input shaft housing and remove the
bottom pipe plug.
b
a
7445
a - Input shaft housing
b - Oil drain pipe plug
!
WARNING
Avoid damage to the input shaft housing. Do Not Overfill the input
shaft housing reservoir or damage to transom components could
occur.
2. Fill the input shaft housing through the top pipe plug hole "a" until oil
flows from oil level pipe plug hole "b." Install the pipe plugs "a" & "b"
into the input shaft housing and tighten securely.
7447
b
a
a - Fill pipe plug hole (fill through here)
b - Oil level pipe plug hole
