• Transom clamp screws lubrication fittings.
a - Tilt tube lubrication fittings
b - Transom clamp screws lubrication fittings
• Steering cable lubrication fitting (if equipped) ‑ Steer the outboard to
fully retract the steering cable end into the outboard tilt tube. Lubricate
the steering cable through the fitting.
a - Steering cable lubrication fitting
b - Steering cable end
c - Tilt tube lubrication fittings
!
WARNING
Incorrect cable lubrication can cause hydraulic lock, leading to serious
injury or death from loss of boat control. Completely retract the end of the
steering cable before applying lubricant.
2. Lubricate the following with lightweight oil.
