Mercury 10 EFI FourStroke - Changing the Tiller Handle Throttle Grip Rotation

2. Install the egress grommet.
a - Throttle cable
b - Shift cable
c - Battery cables
d - 14‑pin harness
3. Install the starboard driveshaft housing cover. Carefully align the egress
grommet while installing the driveshaft housing cover. Be certain to
tighten all screws to the specified torque.
63136
Description
Nm lb‑in. lb‑ft
Driveshaft housing cover screws 6 53 –
Changing the Tiller Handle Throttle Grip Rotation
The engine tiller handle throttle grip rotation can be changed to rotate in the
opposite direction from the factory installation.
1.
Remove the starboard driveshaft housing cover. Refer to Driveshaft
Housing Cover Removal and Installation.
2. Install a flag (tape) onto the top throttle cable.
a
b
c
d
63135
ENGINE INSTALLATION
eng 121
