Model Year Production Code
The serial number decal lists the year of manufacture as an alpha code. This
code can be deciphered into a corresponding number utilizing the following
table.
Serial number decal alpha code
Model Year Manufactured Code
Alpha Production Code A B C D E F G H K X
Corresponding Number 1 2 3 4 5 6 7 8 9 0
Examples:
• XX = 2000
• HK = 2089
• AG = 2017
Specifications—10 HP
Attributes
Specification
Power rating 7.4 kW (10 hp)
Weight
MH 46.7 kg (103 lbs)
MLH 48.5 kg (107 lbs)
E 47.6 kg (105 lbs)
EL 49 kg (108 lbs)
Engine idle speed
Not in gear 900–1000 RPM
In gear 900–1000 RPM
Recommended RPM range at WOT 5700–6200 RPM
Bore x stroke
61.0 mm x 57.0 mm
(2.402 in. x 2.244 in.)
Compression ratio 10.0:1
GENERAL INFORMATION
16 eng
