Mercury 225 HP User Manual

225 (4-STROKE) INSTALLATION MANUAL
Page 16 of 16
Trim Tab Adjustment
The trim tab can be adjusted within limits to help compensate for steering torque.
Adjust trim tab as follows:
1. If boat tends to pull to the right, move the rear edge of the trim tab to the right.
2. If boat tends to pull to the left, move the rear edge of the trim tab to the left.
NOTE: Trim tab adjustment will have little effect reducing steering torque if the anti-ventila-
tion plate is raised 2 inches (50mm) or more above the boat bottom.

Mercury 225 HP Specifications

General

Engine Type	V6
Displacement	3.4L
Full Throttle RPM	5000-5800
Fuel Induction System	Electronic Fuel Injection (EFI)
Starting	Electric
Gear Ratio	1.85:1
Horsepower	225 HP
Cylinders	6
Exhaust	Through Prop
Steering	Hydraulic
Shaft Length	20 in / 25 in / 30 in
Weight	505 lbs (229 kg)
