Mercury 4-STROKE User Manual

b. Move the remote control handle from neutral into reverse and advance
the handle to full speed position. Slowly return the handle back to the
neutral. Place a mark ("b") on the cable next to the end guide.
c. Make a center mark ("c"), midway between marks ("a" and "b"). Align
the end guide with this center mark when installing cable to the
engine.
6098
b
c
a
2. Manually shift the outboard into neutral (propeller will rotate freely).
3. Position the remote control handle into neutral.
4. Attach the shift cable to the shift lever with a washer and cotter pin
retainer.
5. Adjust the cable barrel so the center mark on the cable is aligned with the
end guide when the cable barrel is placed in the barrel receptacle.
INSTALLATION
116 eng

Mercury 4-STROKE Specifications

General

Engine Type	4-Stroke
Fuel Type	Gasoline
Cooling System	Water-cooled
Ignition System	CDI (Capacitor Discharge Ignition)
Starting	Manual / Electric
Shaft Length	15", 20", 25"
Max Power	Varies by model
Full Throttle RPM Range	Varies by model
Fuel Induction System	EFI / Carbureted
Steering	Remote / Tiller
Weight	Varies by model
Fuel Tank Capacity	Varies by model, some models include external tank
Oil Capacity	Varies by model
