3. Place a block of wood between gearcase and propeller to prevent rotation
and tighten propeller nut. Secure propeller nut to the shaft with the cotter
pin.
a - Cotter pin
b - Propeller nut
c - Rear thrust washer
d - Propeller
e - Front thrust washer
a
b
c
d
e
27094
INSTALLATION
120 eng

Mercury 4-STROKE Specifications

General

Engine Type	4-Stroke
Fuel Type	Gasoline
Cooling System	Water-cooled
Ignition System	CDI (Capacitor Discharge Ignition)
Starting	Manual / Electric
Shaft Length	15", 20", 25"
Max Power	Varies by model
Full Throttle RPM Range	Varies by model
Fuel Induction System	EFI / Carbureted
Steering	Remote / Tiller
Weight	Varies by model
Fuel Tank Capacity	Varies by model, some models include external tank
Oil Capacity	Varies by model
