4. Remove the three screws holding the flywheel cover on.
a - Flywheel cover screws (3)
b - Recoil neutral interlock
c - Fuse holder
5. Remove the flywheel cover.
6. Remote Control models ‑ Ensure the key switch is in the "ON" position.
!
WARNING
High voltage is present any time the key is turned on, especially when
starting or operating the engine. Do not touch ignition components or metal
test probes and stay clear of spark plug leads when performing live tests.
!
WARNING
The exposed moving flywheel can cause serious injury. Keep your hands,
hair, clothing, tools, and other objects away from engine when starting or
running the engine. Do not attempt to reinstall the flywheel cover or top
cowl when engine is running.
7. Refer to the appropriate starting procedure (cold or hot).
a
b
a
a
c
28614
OPERATION
eng 75

Mercury 4-STROKE Specifications

General

Engine Type	4-Stroke
Fuel Type	Gasoline
Cooling System	Water-cooled
Ignition System	CDI (Capacitor Discharge Ignition)
Starting	Manual / Electric
Shaft Length	15", 20", 25"
Max Power	Varies by model
Full Throttle RPM Range	Varies by model
Fuel Induction System	EFI / Carbureted
Steering	Remote / Tiller
Weight	Varies by model
Fuel Tank Capacity	Varies by model, some models include external tank
Oil Capacity	Varies by model
