OUTBOARD INSTALLATION
81
1. Position the remote control into neutral.
N
26838
2. Fit the throttle cable through the rubber grommet.
a
b
28491
a - Rubber grommet b - Throttle cable
3. Attach the throttle cable to the throttle lever with a cotter pin retainer.
4. Adjust cable barrel until the barrel slips onto the mounting stud.
