Mercury 40 4-Stroke User Manual

OUTBOARD INSTALLATION
82
5. Fasten the throttle cable to the mounting stud with a flat washer and locknut. Tighten the locknut
to the specified torque.
28494
b
a
c
d
e
a - Throttle cable
b - Cotter pin retainer
c - Flat washer
d - Locknut
e - Cable barrel
Description Nm lb. in. lb. ft.
Throttle cable locknut 6 53
6. Reinstall the access cover with two bolts. Tighten the bolts to the specified torque.
28500
a
a -
Access cover

Mercury 40 4-Stroke Specifications

General

Engine Type	4-Stroke
Horsepower	40 hp
Cylinders	3
Fuel Induction System	Electronic Fuel Injection (EFI)
Starting	Electric
Displacement	747 cc
Shaft Length	20 in
Dry Weight	216 lbs
Steering	Remote
Alternator Amp	18 amp / 226 watt
Full Throttle RPM	5500 - 6000 RPM
