OUTBOARD INSTALLATION

104

INSTALLING OUTBOARD

Drilling Outboard Mounting Holes

1. Mark four mounting holes on the transom using the transom

drill fixture.

or69-1

a - Drill guide holes

b - Transom drilling fixture

c - Transom center line

Transom Drilling Fixture 91‑98234A2

5489

Aids in engine installation by

acting as a template for engine

mounting holes.
