OUTBOARD INSTALLATION

114

BATTERY CABLE CONNECTIONS

Single Outboard

(+)

(-)

or86

a - Red sleeve ‑ positive (+)

b - Black sleeve ‑ negative

(–)

c - Cranking battery
