Mercury 50 4-Stroke User Manual

FEATURES & CONTROLS
48
NOTE: To maintain proper adjustment, the locknut located on top
of the steering friction lever pivot shaft can be tightened.
a
b
c
26811
a - Tighten friction
b - Loosen friction
c - Locknut
REMOTE STEERING MODELS
!
WARNING
Insufficient friction adjustment can cause serious injury or death
due to loss of boat control. When setting the friction adjustment,
maintain sufficient steering friction to prevent the outboard from
steering into a full turn if the tiller handle or steering wheel is
released.

Mercury 50 4-Stroke Specifications

General

Engine Type	4-Stroke
Horsepower	50 hp
Cylinders	3
Starting System	Electric
Steering	Remote
Displacement	747 cc
Fuel Induction System	EFI
Alternator Amp	18 amp
Shaft Length	20 in
Full Throttle RPM Range	5000-6000 RPM
WOT Range	5000-6000 RPM
Fuel Tank Capacity	External Tank Required
