Mercury 50 4-Stroke User Manual

OPERATION
54
3. Set the lanyard stop switch to "RUN" position. Refer to
General Information ‑ Lanyard Stop Switch.
19791
4. Shift outboard to neutral ("N") position.
N
26838
5. Move the throttle‑only lever to the fully closed position or press
the throttle‑only button.
a
b
a
b
26840
a - Fully closed position
b - Maximum fast idle speed position
6. Starting a flooded engine ‑ Advance the throttle‑only lever or
control handle to the maximum throttle‑only position and
continue to crank the engine for starting. Immediately reduce
engine speed after engine starts.

Mercury 50 4-Stroke Specifications

General

Engine Type	4-Stroke
Horsepower	50 hp
Cylinders	3
Starting System	Electric
Steering	Remote
Displacement	747 cc
Fuel Induction System	EFI
Alternator Amp	18 amp
Shaft Length	20 in
Full Throttle RPM Range	5000-6000 RPM
WOT Range	5000-6000 RPM
Fuel Tank Capacity	External Tank Required
