Mercury 50 4-Stroke User Manual

MAINTENANCE
84
•
!
WARNING
Incorrect cable lubrication can cause hydraulic lock, leading to
serious injury or death from loss of boat control. Completely
retract the end of the steering cable before applying lubricant.
Steering Cable Grease Fitting (If equipped) ‑ Rotate
steering wheel to fully retract the steering cable end into
the outboard tilt tube. Lubricate through fitting.
b
a
28468
a - Fitting
b - Steering cable end
3. Lubricate the following with light weight oil.
• Steering Link Rod Pivot Points ‑ Lubricate points.
28471

Mercury 50 4-Stroke Specifications

General

Engine Type	4-Stroke
Horsepower	50 hp
Cylinders	3
Starting System	Electric
Steering	Remote
Displacement	747 cc
Fuel Induction System	EFI
Alternator Amp	18 amp
Shaft Length	20 in
Full Throttle RPM Range	5000-6000 RPM
WOT Range	5000-6000 RPM
Fuel Tank Capacity	External Tank Required
