CYLINDER BLOCK AND CRANKCASE
90-857138R1 MAY 2000 Page 4B–41
24. Reinstall the oil pump.
25. Prime the oil pump by pouring approximately 1 fl oz. (30 ml) of engine oil into the oil pump
inlet side.
c
d
e
a
b
f
g
h
110
110
4-Stroke Outboard Oil (92-828000A12)
a-Bolt (2) M6 X 16 mm
b-Cover
c-O-Ring Seal
d-Rotor - Outer
e-Rotor - Inner
f-Pin
g-Match the Pin With the Pocket in the Inner Rotor
h-Pour Approximately 1 fl oz. (30 ml) of Engine Oil into the Oil Pump Inlet Side
Oil Pump Cover Bolt Torque
70 lb-in. (8 Nm)

Mercury 6 SERIES Specifications

General

Starting	Manual
Cylinders	1
Steering	Tiller
Horsepower	6 HP
Full Throttle RPM Range	5000 - 6000 RPM
Fuel Type	Gasoline
