Section 2 - Getting to Know Your Power Package
90-8M0074352 eng OCTOBER 2012 Page 23
Accidental or unintended activation of the switch during normal operation is also a possibility. This could cause any, or all, of
the following potentially hazardous situations:
• Occupants could be thrown forward due to unexpected loss of forward motion, a particular concern for passengers in the
front of the boat who could be ejected over the bow and possibly struck by the propulsion or steering components.
• Loss of power and directional control in heavy seas, strong current, or high winds.
• Loss of control when docking.
!
WARNING
Avoid serious injury or death from deceleration forces resulting from accidental or unintended stop switch activation. The boat
operator should never leave the operator's station without first disconnecting the stop switch lanyard from the operator.
Instrumentation
Troll Control Speed Range Specification
Troll Control Speed Range Specification
Engine Model RPM
8.2 Mag 600–1000
8.2 Mag H.O. 650–1200
Digital Gauges
A Mercury SmartCraft System instrument package can be purchased for this product. A few of the functions the instrument
package will display are engine RPM, coolant temperature, oil pressure (requires a SmartCraft oil pressure sender kit), battery
voltage, fuel consumption, and engine operating hours.
SmartCraft digital gauges also feature troll control. This allows a vessel to maintain a constant speed with an engine speed
between the specified RPM range.
SmartCraft gauges
a - Tachometer
b - Speedometer
c - LCD system view display
The SmartCraft instrument package also aids in Engine Guardian diagnostics. The SmartCraft instrument package displays
critical engine alarm data and potential problems.
Refer to the manual with your gauge package for the warning functions monitored by and basic operation of the SmartCraft
instrument package.
