ENGINE INSTALLATION
114
b. Move the remote control handle from neutral into reverse
and advance the handle to full speed position. Slowly return
the handle back to the neutral. Place a mark ("b") on the
cable next to the end guide.
c. Make a center mark ("c"), midway between marks ("a" and
"b"). Align the end guide with this center mark when
installing cable to the engine.
2. Manually shift the outboard into neutral (propeller will rotate
freely).
3. Position the remote control handle into neutral.
4. Attach the shift cable to the shift lever with a washer and cotter
pin retainer.
5. Adjust the cable barrel so the center mark on the cable is
aligned with the end guide when the cable barrel is placed in
the barrel receptacle.
