OUTBOARD INSTALLATION

20791

a - 14 pin connector b - Remote 14 pin boat harness

SMARTCRAFT HARNESS CONNECTION

If SmartCraft gauges are being used with the outboard, route the SmartCraft wiring harness through the front

grommet and connect it to the SmartCraft harness connector on the engine.

20895

a - SmartCraft harness connector
