ENGINE INSTALLATION
eng 127
BOAT TRANSOM HEIGHT REQUIREMENT
1. Measure the transom height of your boat. The boat bottom
should be aligned or be within 25 mm (1 in.) above the
anti‑ventilation plate of the outboard.
a - Anti‑ventilation plate
INSTALLING OUTBOARD ON TRANSOM
1. Place the outboard on the centerline of the transom.
27005
2. Tighten the transom bracket clamp screws.
28501
a
27151
