Mercury Axius System - Special Digital Throttle and Shift (DTS) Features

Section 2 - On the Water
Page 18 CMD-4082082 / 90-8M0052072 eng FEBRUARY 2011
Joystick Input Boat Response
Movement
(shown from light gray to dark gray)
24715
NOTE: In this maneuver move and twist the
joystick for yaw correction, if required.
Boat moves diagonally forward and rotates
starboard for yaw correction
37774
Special Digital Throttle and Shift (DTS) Features
The DTS system features several alternate operational modes for various Electronic Remote Control (ERC) levers. Any of the
listed features can operate simultaneously.
i
a
b
c
d
e
f
g
h
a
39563
Typical ERC levers with trim control and DTS trackpad
28090
c
d
e
f
g
b
a
h
Yacht handled ERC levers with DTS trackpad
