INSTALLATION MANUAL
90-864198020 Page 9 of 77
c
25506
a
b
d
e
b
ZF / Hurth 630A or 800A - 8 Degree Down-Angle Transmissions
72959
a
b
c
d
e
b
ZF / Hurth 630V - V-Drive Transmissions
a-Direction Of Shift Lever Engagement (Toward Flywheel)
b-Engine/Transmission Input Shaft Rotation Direction (LH)
c-Transmission Output/Propeller Shaft Rotation Direction (LH)
d-Direction Of Shift Lever Engagement (Away From Flywheel)
e-Transmission Output/Propeller Shaft Rotation Direction (RH)
