GASOLINE ENGINES SKI MODELS
Page 24 of 48
8. Bend one of the tabs on tab washer down onto flat of adjusting nut.
70646
d
a
a
b
c
a-Clamping Screws and Nuts
b-Locknut
c-Tab On Tab Washer
d-1-3/4 in. (45 mm)
9. Connect propeller shaft coupler to transmission output flange. Secure coupling together
with bolts, lockwashers and nuts. Torque to 50 lb-ft (68 Nm).
Seawater Pickup Pump Connection
1. Remove shipping cap. Connect seawater inlet hose to inlet fitting (bottom hose) on sea-
water pump.
75533
a
a-Seawater Inlet Hose
To Next Page
