Section 3 - Screen Overview and Operation
90-8M0087257 eng DECEMBER 2014 Page 35
• The enter button is not required for the field above the footer area.
a - Profile selection
b - Set point value
c - Enable
d - Save
e - Exit
Profile selection allows you to select from the five factory preset profiles and any custom settings you have created. Custom
settings can be modified and will default to the last known settings. The enter button does not need to be pressed to accept and
save changes.
Factory preset profiles
The set‑point value will allow the operator to adjust the RPM or speed set‑point. These will default to 10 mph or 1700 RPM until
the operator quick saves the values.
• Set‑point is the default selection when Smart Tow is active. The operator can adjust the RPM or speed by pressing the
arrow keys.
a - Set‑point default selection
After the operator makes adjustments to the desired settings, pressing the pages button will move the cursor to the enable
selection in the footer area of the user‑selected data area.
• Enable or disable turns the feature on or off. The persistent data RPM sweeps will be displayed as non‑active white
sweeps. The operator can modify all settings when the system is in the off state.
a. The Enable icon will be green when active
