Mercusys MW300RE User Guide

MW300RE
300Mbps Wi-Fi Range Extender
FAQ (Frequently Asked Questions)
Q1. How to restore my extender’s configuration to its factory default settings?
Option One: With the extender powered on, press and hold the RESET/WPS button for more
than 5 seconds until the Signal LED starts blinking quickly, then release the button.
Option Two: Log in to the extender’s web management page via a web browser, go to System
Tools > Factory Default Restore, and click Factory Default Restore.
Q2. What should I do if I forgot my login password?
Restore the extender’s configuration to its factory default settings referring to Q1, then create
a new password when prompted.
Q3. What should I do if I cannot log in to the extender's web management page?
• Make sure your wireless device is connected to the extended network using the extended
SSID.
• Verify that http://mwlogin.net is correctly entered in the web browser.
• If you are using a computer, make sure it is set to obtain an IP address automatically.
• Refer to Q1 to reset the extender and try again.
- 18 -

Mercusys MW300RE Specifications

General

Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Certification	CE
Product color	White
LED indicators	Yes
Sustainability certificates	RoHS
Antenna type	External
Antennas quantity	3
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK
Wi-Fi data rate (max)	300 Mbit/s
Power consumption (max)	4.3 W
Power consumption (typical)	3 W
Type	Network repeater
Maximum transfer distance	- m
Package depth	121.5 mm
Package width	150.5 mm
Package weight	250 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	74.8 mm
Width	101 mm
Height	75.8 mm
