1. Recommended bushel capacities for Meridian AirMax® system. 2. Recommended bin model(s) for maximum grain drying and aeration results. 3. Distance from gate to top of aeration mechanism.
Table 2 - Meridian Airmax® Specifications
Models
Max Bin Size
(Bushels)
1
Recommended
Hopper Bin Size
2
Dimensions
Dia.
I.D.
Weight
(LB)
Screen
Surface
(Inches)
Inlet Size
and Type
Height into
Grain Cavity
35° Cone
3
Height into
Grain Cavity
40° Cone
3
Height into
Grain Cavity
55° Cone
3
Vertical Aeration – One Piece
V3004 3500
14’ & 16’ bins up to 3500 bushels.
Models 1615. GM3 and smaller
30” x 4’ 20” 385 6299
9” x 14”
Rect
n/a 86” n/a
V3006 5000
14’ & 16’ bins up to 5000 bushels.
Models 1625. GM5 and smaller
30” x 6’ 20” 440 9656
9” x 14”
Rect
n/a 110” n/a
V3008 6000
14’ & 16’ bins up to 6000 bushels.
Models 1630. GM6 and smaller
30” x 8’ 20” 525 13132
9” x 14”
Rect
n/a 134” n/a
V4504 7000
14’, 16’ & 18” bins up to 7000 bushels.
Models 1825. GM64 and smaller
45” x 4’ 30” 580 9301
14” x 17”
Rect
n/a 95” n/a
Vertical Aeration – Sectional (Designed for Retrofitting Existing Hopper Bins and High-Flow Applications)
4
VS3004 5000 All bins up to 5000 bushels 30” x 4’ 20” 420 5245
9” x 14”
Rect
80” 86” 99”
VS3006 8000 All bins up to 8000 bushels 30” x 6’ 20” 500 7990
9” x 14”
Rect
104” 110” 123”
VS4504 15000 All bins up to 15000 bushels 45” x 4’ 30” 600 7925
14” x 17”
Rect
88” 95” 116”
VS4506 20000 All bins up to 20000 bushels 45” x 6’ 30” 745 12100
14” x 17”
Rect
112” 119” 140”
Horizontal Aeration (Removable for Fertilizer Storage and Available for Retrofitting Existing Bins)
H1808 5000
14’ & 16’ bins up to 3300 bushels.
Models 1615. GM3 and smaller
18” x 8’ n/a 155 3478 18” Rnd 38” 44” n/a
H2408 6500
14’, 16’ & 18’ bins up to 5000 bushels.
Models 1625, 1820, GM500 and smaller
24” x 8’ n/a 235 4660 24” Rnd 44” 50” n/a
H2410 6500
14’, 16’ & 18’ bins up to 6500 bushels.
Models 1630, 1825, GM6, GM64
and smaller
24” x 10’ n/a 285 6284 24” Rnd 51” 59” n/a
H2410-HD 8,500 Up to 18’ diameter 24” x 10' 24” 360 6284 24" Rnd 51” 59” n/a H2412-HD 11,000 Up to 20’ diameter 24” x 12' 24” 425 7908 24" Rnd 58” 68” n/a
4. Meridian AirMax® Sectional system is an exclusive and unique aeration product
allowing installation of vertical aeration in existing hopper bins. This unit is built heavier than the one-piece AirMax™, withstanding weights up to 20,000 bushels.
