Meridian SMOOTHWALL BIN - Section 7: REFERENCE; 7.5 MULTI-PURPOSE BIN SPECIFICATIONS

03.2020 7-7
Owner’s Manual: Smoothwall Bin
®
Table 15 - Western Canada
MODEL DESCRIPTION
APPROX.
BUSHELS
CUBIC FEET IMP. TONS
METRIC
TONNES
BIN
HEIGHT
REC.
AUGER
1205
12’ Diameter
45° Bottom Cone
804 947 29 26 16’ 8” 33’
1208 1,093 1,286 39 36 19’ 8” 39’
1210 1,284 1,511 46 42 21’ 8” 39’
1212 1,476 1,737 53 48 23’ 8” 39’
1215 1,763 2,075 64 58 26’ 8” 46’
1410
14’ Diameter
45° Bottom Cone
1,823 2,145 66 60 23’ 4” 39’
1412 2,084 2,452 76 68 25’ 4” 46’
1415 2,476 2,913 90 81 28’ 4” 53’
1417 2,737 3,220 99 90 30’ 4” 53’
1420 3,128 3,681 114 103 33’ 4” 59’
15610
15’ 6” Diameter
40° Bottom Cone
2,237 2,632 81 74 23’ 9” 41’
15612 2,556 3,008 93 84 25’ 9” 46’
15615 3,037 3,573 110 100 28’ 9” 53’
15617 3,357 3,950 122 111 30’ 9” 53’
15620 3,836 4,513 139 126 33’ 9” 59’
15625 4,636 5,455 169 153 38’ 9” 66’
15630 5,434 6,394 198 179 43’ 9” 72’
1610
16’ Diameter
40° Bottom Cone
2,405 2,830 87 79 23’ 11” 46’
1612 2,746 3,231 100 90 25’ 11” 46’
1615 3,258 3,833 118 107 28’ 11” 53’
1617 3,599 4,235 131 119 30’ 11” 53’
1620 4,109 4,835 149 136 33’ 11” 59’
1625 4,961 5,837 180 164 38’ 11” 66’
1630 5,813 6,839 212 192 43’ 11” 72’
1810
18’ Diameter
40° Bottom Cone
3,155 3,712 115 104 25’ 6” 46’
1815 4,233 4,981 154 140 30’ 6” 53’
1820 5,312 6,250 193 175 35’ 7” 59’
1825 6,392 7,520 233 211 40’ 6” 66’
1830 7,470 8,789 272 247 45’ 6” 79’
7.5 MULTI-PURPOSE BIN SPECIFICATIONS
16’
Bin Diameter
20’
Sidewall
