Meridian SMOOTHWALL BIN - Section 7: REFERENCE; 7.9 STEEP CONE BIN SPECIFICATIONS

7-12 3.2020
Owner’s Manual: Smoothwall Bin
®
Table 24 - Western Canada
MODEL DESCRIPTION
APPROX.
BUSHELS
CUBIC
FEET
IMP. TONS
METRIC
TONNES
BIN HEIGHT
REC.
AUGER
1208-55
12’ Diameter 55°
Bottom Cone
1178 1382 39 25 22' 46'
1210-55 1371 1607 45 29 24' 46'
1212-55 1563 1833 52 33 26' 46'
1215-55 1851 2171 61 39 29' 53'
1410-55
14’ Diameter 55°
Bottom Cone
1928 2297 65 42 26' 46'
1412-55 2187 2605 73 47 28' 53'
1415-55 2576 3065 86 56 31' 59'
1417-55 2835 3372 95 61 33' 66'
1420-55 3224 3833 108 70 36' 66'
15.510-55
15’ 6” Diameter
55° Bottom Cone
2447 2917 82 53 28' 53'
15.512-55 2765 3293 93 60 30' 59'
15.515-55 3242 3858 109 70 33' 66'
15.517-55 3559 4235 119 77 35' 66'
15.520-55 4036 4800 135 87 38' 66'
15.525-55 4830 5741 161 104 43' 72'
15.530-55 5621 6678 188 121 48' 85'
1610-55
16’ Diameter 55°
Bottom Cone
2638 3144 88 57 28' 53'
1612-55 2976 3545 100 64 30' 59'
1615-55 3484 4147 117 75 33' 66'
1617-55 3823 4548 128 83 35' 66'
1620-55 4330 5150 145 93 38' 66'
1625-55 5177 6153 173 112 43' 72'
1630-55 6019 7152 201 130 48' 85'
16’
Bin Diameter
10’
Sidewall
55
O
Cone Angle
7.9 STEEP CONE BIN SPECIFICATIONS
