Meridian SMOOTHWALL BIN - Section 7: REFERENCE; 7.7 QUICK-WEIGH HOPPER BIN SPECIFICATIONS; 7.8 DUMP HOPPER BIN SPECIFICATIONS

03.2020 7-11
Owner’s Manual: Smoothwall Bin
®
7.7 QUICK-WEIGH HOPPER BIN SPECIFICATIONS
7.8 DUMP HOPPER BIN SPECIFICATIONS
Used with underbin conveyer seed sites
Table 22 - Western Canada
MODEL DESCRIPTION CAPACITY CLEARANCE HEIGHT UNITS
801QW
8’ Diameter
35° Bottom
5000 lb 3’ 0” 6’ 9-1/2” 100
801QW 5000 lb 8’ 6” 12’ 2-1/2” 100
801QW 5000 lb 11’ 6” 15’ 3-1/2” 100
805QW 15000 lb 3’ 0” 10’ 9-1/2” 300
805QW 15000 lb 8’ 6” 16’ 3-1/2” 300
805QW 15000 lb 11’ 6” 19’ 3-1/2” 300
1005QW
10’ Diameter
35° Bottom
25000 lb 3’ 0” 12’ 10” 500
1005QW 25000 lb 8’ 6” 18’ 4” 500
1005QW 25000 lb 11’ 6” 21’ 4” 500
Table 23 - Western Canada
MODEL DESCRIPTION CAPACITY CLEARANCE HEIGHT UNITS
801DH
8’ Diameter
35° Bottom
5000 lb 3’ 0” 6’ 10” 100
801DH 5000 lb 4’ 4” 8’ 2” 100
805DH 15000 lb 11’ 6” 19’ 4” 300
805DH 15000 lb 3’ 0” 10’ 10” 300
801DH 5000 lb 11’ 6” 15’ 3-1/2” 100
805DH 15000 lb 8’ 6” 16’ 3-1/2” 300
1005DH
10’ Diameter
35° Bottom
25000 lb 3’ 0” 12’ 10” 500
1005DH 25000 lb 11’ 6” 21’ 4” 500
1005DH 25000 lb 8’ 6” 18’ 4” 500
